Specifications
| Model : TRU | Max E-11000 |
| RATED POWER | 11000VA/ 11000W |
| Parallel Capability | Yes, 6 units |
| INPUT | |
| Voltage | 230 VAC |
| Selectable Voltage Range | 170-280 VAC (For Personal Computers) 90-280 VAC (For Home Appliances) |
| Frequency Range | 50Hz / 60Hz (Auto sensing) |
| OUTPUT | |
| AC Voltage Regulation (Batt. Mode) | 230VAC ± 5% |
| Surge Power | 22000VA |
| Efficiency (Peak) | 93% |
| Transfer Time | 10 ms (For Personal Computers); 20 ms (For Home Appliances). |
| Waveform | Pure sine wave |
| No Load Power Consumption | < 70 W |
| Dual Outputs | Yes |
| BATTERY | |
| Battery Voltage | 48 VDC |
| Floating Charge Voltage | 54 VDC |
| Overcharge Protection | 63 VDC |
| SOLAR CHARGER & AC CHARGER | |
| Solar Charger Type | MPPT |
| Maximum PV Array Power | 11000W |
| MPPT Range @ Operating Voltage | 90VDC ~ 450VDC |
| Maximum PV Array Open Circuit Voltage | 500VDC |
| Maximum Solar Charge Current | 150A |
| Maximum AC Charge Current | 150 A |
| Maximum Charge Current | 150 A |
