Product Paramenters
Product ParamentersDatasheet | SPF 3500 ES Plus | |
Battery Voltage | 48VDC | |
Battery Type | Lithium/Lead-acid | |
Inverter Output | ||
Rated Power | 3500 Watt | |
Parallel Capability | Yes, 6 units maximum | |
AC Voltage Regulation(Battery Mode) | 230VAC ± 5% @ 50/60Hz | |
Surge Power | 7000VA | |
Efficiency (Peak) | 93% | |
Waveform | Pure sine wave | |
Transfer Time | 10ms typical,20ms Max | |
Solar Charger | ||
Maximum PV Array Power | 4500 Watt | |
MPPT Range @ Operating Voltage | 120VDC ~ 430VDC | |
Number of Independent MPP Trackers/ Strings Per MPP Tracker | 1 | |
Max. input current per MPP tracker | 16A | |
Maximum PV Array Open Circuit Voltage | 450VDC | |
Maximum Solar Charge Current | 80A | |
AC Charger | ||
Charge Current | 60A | |
AC Input Voltage | 230VAC | |
Selectable Voltage Range | 170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances) | |
Frequency Range | 50Hz/60Hz (Auto sensing) | |
Cooling | Physical | |
Protection Degree | IP20 | |
Dimension (W/H/D) | 330*485*135 mm | |
Net Weight (kgs) | 11.5 kg | |
Operating Environment | ||
Humidity | 5% to 95% Relative Humidity(Non-condensing) | |
Altitude | <2000m | |
Operating Temperature | 0°C - 55°C | |
Storage Temperature | -15°C - 60°C | |
