ELECTRICAL DATA Rated Maximum Power (Pmax) 150W Voltage at Pmax (Vmp) 18V Current at Pmax (Imp) 8.36A Open-Circuit Valtage (Voc) 21.43V Short-Circuit Current (Isc) 9.44A Module Efficiency (%) 20.17% Operating Temperature( C) -40° C~+85°C°C Maximum System Voltage 1000V Maximum Series Fuse 20A Power Tolerance O~士3% Application Class Class =

SPECIFICATIONS Cell Type Ntype Mono No. of cells 64 Dimensions 765110030mm Weight 8.1kg Glass 3.2mm UItra-white cloth-textured tempered glass Frame Anodized Aluminium Alloy Junction Box PVCQ210 Output Cables 2R+300mm²+MC4 or Customized Length
